Portable Above Ground Storage for High-Volume Water Management

Above ground storage tanks are portable containment systems used to store large volumes of water without constructing an in-ground impoundment. For projects that require temporary or semi-permanent storage, an AST can reduce site disturbance, shorten setup time, and provide a controlled storage area for fresh water, produced water, flowback water, or recycled water.

Mustang Containment Solutions installs above ground storage systems that can be deployed, lined, filled, and later removed or relocated as project needs change.

Epic 360 Above Ground Storage Tank

The Epic 360 is a bolt-together portable storage tank system designed for high-volume water storage. The system can be transported to a project site, assembled with heavy equipment, lined for the intended fluid, and placed into service after installation and inspection.

The system may be used as part of water treatment, reuse, and blending operations where large-volume storage is required

Above Ground Storage Tank Benefits

  • Quick setup
  • Portable system that can be relocated or removed
  • May reduce trucking needs
  • Reduced site disturbance compared with some in-ground storage options
  • Rated for use as primary and secondary containment
  • Secure bolt-together wall design
  • Can be lined for produced water or fresh water
  • Available in sizes from 10,000 BBL to 46,000 BBL

Above Ground Storage Tank Sizes

DiameterCapacityGallons
76 ft10,000 BBL420,000
83 ft12,000 BBL504,000
115 ft22,000 BBL924,000
125 ft26,000 BBL1,092,000
153 ft40,000 BBL1,680,000
165 ft46,000 BBL1,932,000
